Hjem / Produkter / TRL blæsere

Transportblæsere

TRL blæsere

Højtryksblæser egnet til både suge- og blæsesystemer samt til suge-blæsesystemer

TRL-serien med tilbehør er ideel til transport af granulært materiale og lignende produkter. De er også velegnede til de fleste sugeopgaver, f.eks. til sugning af svejserøg og mange ventilationsopgaver.

Kongskilde TRL højtryksblæsere fås i en lang række størrelser – med en række forskellige egenskaber, der kan opfylde specifikke industrielle krav.

TRL højtryksblæsere

TRL-blæserens aerodynamiske form sikrer høj effektivitet og lavt energiforbrug. Blæserne er konstrueret som en centrifugalventilator med en perfekt afbalanceret rotor og dermed en vibrationsfri drift, hvilket minimerer støjniveauet. TRL-serien af blæsere er utroligt alsidige i deres anvendelse.

TRL-luftregulator

Ved at kombinere blæseren med en luftregulator optimeres lufthastigheden, hvilket minimerer skader på materialet, selv når der transporteres sarte materialer. Den konstante lufthastighed forhindrer også, at motoren overbelastes, og minimerer strømforbruget.

Funktioner

  • The small and medium-sized blowers are one-stage centrifugal blowers with closed rotors, whereas TRL 300 and 500 have two respectively three stages, which also are equipped with, closed rotors.
  • Select models are equipped with air regulators.
  • Smaller models can be used as either a transport blower or suction blower.
  • Many midsize and large models can be utilized for both suction and blowing systems, or as a combination of a suction-blowing system.
  • The material does not pass through the blower.

Fordele

  • Minimal space for installation, the conveying pipes can reach anywhere.
  • Low weight of the conveying pipe means only small loads on buildings.
  • No heavy components to be installed in inaccessible places.
  • Wide range of modular pipe components and junctions means flexible installation options.
  • Only electrical installation to the blower and rotary valve intake, which are centrally located.
  • Easy capacity regulation with shutter on the inlet of the rotary valve intake unit.
  • Maximum capacity is achieved with pressure conveying.

Sammenligning af TRL-modeller

Sammenlign de tilgængelige TRL-blæsermodeller. Besøg afsnittet downloads for at få flere oplysninger om specifikke modeller.

TRL 20TRL 40TRL 55TRL 75TRL 100TRL 150TRL 200
Motorens omdrejningstal2900290029002900290029002900
Amp. Forbrug3.14.47.510.5202733
Motorens effekt, kW (HK)1.5 (2)3 (4)4 (5.5)5.5 (7.5)7.5 (10)11 (15)15 (20)
TRL 300TRL 500TRL 600TRL 750TRL 1000TRL 1250TRL 1500
Motorens omdrejningstal2900290029002900290030003000
Amp. Forbrug39657896129150185
Motorens effekt, kW (HK)22 (30)37 (50)45 (60)55 (75)75 (100)90 (125)110 (150)
